Description
The Carrier QHF Elite Plus inverter midwall split range is a higher-capacity hi-wall line using R410A refrigerant, with inverter technology for efficient cooling and heating across larger rooms and open-plan spaces.
Features
- ✓Inverter technology for variable compressor operation
- ✓Uses R410A refrigerant
- ✓Smart LCD infrared remote with full control functions
- ✓Louver position memory and auto fan-speed
- ✓Independent dehumidification mode
- ✓Turbo function, ECO/quiet sleep mode and smart self-diagnostics
What's included in the installation
The installed price covers a standard back-to-back installation by our technicians.
Included
- ✓Indoor unit mounted, with the outdoor unit fitted directly outside (back-to-back)
- ✓Refrigerant pipe set, insulation and mounting brackets
- ✓Condensate drain and a short wall penetration
- ✓Indoor–outdoor interconnecting wiring
- ✓Vacuum, commissioning and a refrigerant leak check
Not included
- –Pipe and cable runs beyond a basic back-to-back layout, or trunking over distance
- –Distribution-board (DB) work, dedicated circuits and the Certificate of Compliance
- –Core drilling through difficult structures, crane or scaffolding access
This 32,000 BTU inverter unit needs a dedicated circuit.
Because it draws more than a standard wall socket allows, it must be connected to your distribution board (DB) by a registered electrician on its own circuit.
In South Africa this is electrical installation work that requires a Certificate of Compliance (SANS 10142-1 / the Electrical Installation Regulations).
You arrange this connection with your own registered electrician — it is not part of the back-to-back installation price.
Exact scope is confirmed on site before work begins, and installation availability and final pricing are confirmed with your quote.
Technical specifications
| General | |
|---|---|
| Brand | Carrier |
| Model | QHF032DS-1 |
| Indoor model | 42QHF032DS-1 |
| Outdoor model | N/A |
| Type | Midwall Split |
| BTU | 32,000 |
| Cooling capacity | 9.20 kW |
| Heating capacity | 9.80 kW |
| Inverter | Yes |
| Refrigerant | R410A |
| Energy rating | Cooling B / Heating A+ |
| COP/EER | 3.59 W/W |
| Voltage | 220-240V |
| Phase | 1 |
| Liquid pipe | 3/8" |
| Gas pipe | 5/8" |
| Efficiency | |
| Eer | 3.19 |
| Cop | 3.59 |
| Electrical | |
| Power Input Kw | 2.88 kW |
| Rated Current A | 12.8 A |
| Indoor | |
| Dimensions Indoor Mm | 1259x283x362 |
| Weight Indoor Kg | 19.0 kg |
| Noise Indoor Db | 52.0 dB(A) |
| Pipework | |
| Max Pipe Length M | 40 m |
Specifications from supplier brochures/datasheets. Missing values shown as N/A — confirm critical specs before purchase.
