LG DualCool M-Range Inverter midwall splits are designed for efficient temperature control with inverter compressor technology. The range uses R410A refrigerant and is available in multiple capacities to suit different room sizes, providing both cooling and heating.
Features
- ✓LG DualCool M-Range wall-mounted split
- ✓Inverter compressor technology for efficient, stable operation
- ✓Uses R410A refrigerant
- ✓Available in multiple capacities
- ✓Cooling and heating (heat-pump) operation
What's included in the installation
The installed price covers a standard back-to-back installation by our technicians.
Included
- ✓Indoor unit mounted, with the outdoor unit fitted directly outside (back-to-back)
- ✓Refrigerant pipe set, insulation and mounting brackets
- ✓Condensate drain and a short wall penetration
- ✓Indoor–outdoor interconnecting wiring
- ✓Vacuum, commissioning and a refrigerant leak check
Not included
- –Pipe and cable runs beyond a basic back-to-back layout, or trunking over distance
- –Distribution-board (DB) work, dedicated circuits and the Certificate of Compliance
- –Core drilling through difficult structures, crane or scaffolding access
This 24,000 BTU non-inverter unit needs a dedicated circuit.
Because it draws more than a standard wall socket allows, it must be connected to your distribution board (DB) by a registered electrician on its own circuit.
In South Africa this is electrical installation work that requires a Certificate of Compliance (SANS 10142-1 / the Electrical Installation Regulations).
You arrange this connection with your own registered electrician — it is not part of the back-to-back installation price.
Exact scope is confirmed on site before work begins, and installation availability and final pricing are confirmed with your quote.
Technical specifications
| General | |
|---|---|
| Brand | LG |
| Model | M24AKH |
| Indoor model | N/A |
| Outdoor model | N/A |
| Type | Midwall Split |
| BTU | 24,000 |
| Cooling capacity | 6.45 kW |
| Heating capacity | 6.45 kW |
| Inverter | N/A |
| Refrigerant | R410A |
| Energy rating | N/A |
| COP/EER | 3.41 W/W |
| Voltage | 220–240 V |
| Phase | 1 |
| Liquid pipe | ø6.35 mm |
| Gas pipe | ø15.88 mm |
| Efficiency | |
| Eer | 3.21 |
| Cop | 3.41 |
| Electrical | |
| Power Input Kw | 2.01 kW |
| Rated Current A | 9.6 A |
| Indoor | |
| Dimensions Indoor Mm | 998 x 345 x 210 |
| Weight Indoor Kg | 12.8 kg |
| Noise Indoor Db | 48 dB(A) |
| Pipework | |
| Max Pipe Length M | 20 m |
Specifications from supplier brochures/datasheets. Missing values shown as N/A — confirm critical specs before purchase.
