Description
The LG DualCool Standard Commercial Wi-Fi midwall split range combines LG Dual Inverter technology with R410A refrigerant for efficient, stable climate control in light-commercial spaces. Built-in Wi-Fi and LG ThinQ app compatibility enable convenient remote monitoring and operation, with a compact, modern indoor unit that suits a variety of interiors.
Features
- ✓Dual Inverter compressor technology for energy efficiency and precise control
- ✓Uses R410A refrigerant
- ✓Built-in Wi-Fi with LG ThinQ app support for remote control and scheduling
- ✓Midwall split configuration for a wide range of commercial layouts
- ✓Auto-swing louvres and multiple fan settings
- ✓Self-diagnostic functions with error display to assist service
Technical specifications
| General | |
|---|---|
| Brand | LG |
| Model | M24EKHB NK0 / M24EKHB UK0 |
| Indoor model | N/A |
| Outdoor model | N/A |
| Type | Midwall Split |
| BTU | 24,000 |
| Cooling capacity | 6.45 kW |
| Heating capacity | 6.45 kW |
| Inverter | Yes |
| Refrigerant | R410A |
| Energy rating | A/A+ |
| COP/EER | N/A |
| Voltage | 220-240V |
| Phase | 1 |
| Liquid pipe | ø 6.35 mm |
| Gas pipe | ø 15.88 mm |
| General | |
| Compressor Type | Twin Rotary |
| Eer WW | 3.21 |
| Cop WW | 3.41 |
| Power Input Cooling Rated W | 2010 |
| Power Input Heating Rated W | 1890 |
| Running Current Cooling Rated A | 9.6 |
| Running Current Heating Rated A | 9.1 |
| Indoor Dimensions Net Mm | 998 x 345 x 210 |
| Indoor Weight Net Kg | 11.7 |
| Outdoor Dimensions Net Mm | 870 x 650 x 330 |
| Outdoor Weight Net Kg | 42.9 |
| Max Elevation Difference M | 10 |
| Noise Indoor High Db A | 48 |
| Noise Indoor Sleep Db A | 32 |
| Noise Outdoor Cooling Db A | 56 |
| Operating Range Cooling Db C | 18~48 |
| Operating Range Heating Db C | -5~24 |
| Circuit Breaker A | 20 |
| Refrigerant Pre Charge G | 1350 |
| Refrigerant Additional Charge Per_m_G | 20 |
| Annual Energy Cooling Kwh | 1005 |
| Embedded Wifi | Yes |
| Active Power Control | Yes |
| Pipework | |
| Max Pipe Length M | 20 m |
Specifications from supplier brochures/datasheets. Missing values shown as N/A — confirm critical specs before purchase.
